Anvelope standard
|
10.0/75 - 15.3 AS ET80
10.0/75 - 15.3 AS ET80
|
10.0/75 - 15.3 AS ET80
10.0/75 - 15.3 AS ET80
|
|
|
|
|
A
|
otal length
|
4.053 mm
159,6 in
|
4.276 mm
168,3 in
|
|
|
|
B
|
otal length without bucket
|
3.321 mm
130,7 in
|
3.545 mm
139,6 in
|
|
|
|
C
|
ucket pivot point (to center of axle)
|
534 mm
21,0 in
|
758 mm
29,8 in
|
|
|
|
D
|
heel base
|
1.623 mm
63,9 in
|
1.623 mm
63,9 in
|
|
|
|
E
|
ear overhang
|
1.054 mm
41,5 in
|
1.054 mm
41,5 in
|
|
|
|
F
|
eight with operator's canopy fixed
|
2.255 mm
88,8 in
|
2.255 mm
88,8 in
|
|
|
|
F
|
eight with fold-down operator's canopy (eps)
|
2.373 mm
93,4 in
|
2.373 mm
93,4 in
|
|
|
|
F
|
eight with fold-down operator's canopy, folded down (eps)
|
1.856 mm
73,1 in
|
1.856 mm
73,1 in
|
|
|
|
F
|
eight with cab
|
2.280 mm
89,8 in
|
2.280 mm
89,8 in
|
|
|
|
H
|
eat height
|
1.320 mm
52,0 in
|
1.320 mm
52,0 in
|
|
|
|
J
|
otal working height
|
3.461 mm
136,3 in
|
3.710 mm
146,1 in
|
|
|
|
K
|
ucket pivot point (max. lift height)
|
2.872 mm
113,1 in
|
3.120 mm
122,8 in
|
|
|
|
L
|
oad-over height
|
2.544 mm
100,2 in
|
2.820 mm
111,0 in
|
|
|
|
M
|
umping height
|
2.067 mm
81,4 in
|
2.380 mm
93,7 in
|
|
|
|
N
|
each (at M)
|
265 mm
10,4 in
|
330 mm
13,0 in
|
|
|
|
O
|
igging depth
|
37 mm
1,5 in
|
110 mm
4,3 in
|
|
|
|
P
|
otal width
|
1.044 mm
41,1 in
|
1.044 mm
41,1 in
|
|
|
|
Q
|
rack width
|
780 mm
30,7 in
|
780 mm
30,7 in
|
|
|
|
T
|
aximum radius
|
2.846 mm
112,0 in
|
2.951 mm
116,2 in
|
|
|
|
U
|
adius on the outer edge
|
2.546 mm
100,2 in
|
2.546 mm
100,2 in
|
|
|
|
V
|
nner radius
|
1.423 mm
56,0 in
|
1.423 mm
56,0 in
|
|
|
|
W
|
rticulation angle
|
45 °
45 °
|
45 °
45 °
|
|
|
|
X
|
ollback angle at max. lift height
|
47 °
47 °
|
52 °
52 °
|
|
|
|
Y
|
umping angle
|
44 °
44 °
|
36 °
36 °
|
|
|
|
Z
|
ollback angle on ground
|
48 °
48 °
|
47 °
47 °
|
|
|
