| Engine manufacturer | Perkins |
| Motor type | 904J-E36TA |
| Cylinder | 4 |
| Drive output | 74,4 kW 74,4 kW |
| Drive output | 99,8 HP 101,2 PS |
| At max. rpm | 2.200 rpm 2.200 U/min |
| Cylinder capacity | 220,97 in³ 3.621 cm³ |
| Type of coolant | Wasser |
| Exhaust standard level | V |
| Exhaust aftertreatment | DOC/DPF/SCR |
| Average sound power level LwA (cabin) | 103 dB(A) |
| Guaranteed sound power level LwA (cabin) | 106 dB(A) |
| Specified sound pressure level LpA (cabin) | 76 dB(A) |
| Engine manufacturer | Perkins |
| Motor type | 904J-E36TA |
| Cylinder | 4 |
| Drive output | 90 kW 90 kW |
| Drive output | 120,7 HP 122,4 PS |
| At max. rpm | 2.200 rpm 2.200 U/min |
| Cylinder capacity | 220,97 in³ 3.621 cm³ |
| Type of coolant | Wasser |
| Exhaust standard level | V |
| Exhaust aftertreatment | DOC/DPF/SCR |
| Average sound power level LwA (cabin) | 105 dB(A) |
| Guaranteed sound power level LwA (cabin) | 106 dB(A) |
| Specified sound pressure level LpA (cabin) | 76 dB(A) |
| Engine manufacturer | Perkins |
| Motor type | 904J-E36TA |
| Cylinder | 4 |
| Drive output | 100 kW 100 kW |
| Drive output | 134,1 HP 136 PS |
| At max. rpm | 2.200 rpm 2.200 U/min |
| Cylinder capacity | 220,97 in³ 3.621 cm³ |
| Type of coolant | Wasser |
| Exhaust standard level | V |
| Exhaust aftertreatment | DOC/DPF/SCR |
| Average sound power level LwA (cabin) | 105 dB(A) |
| Guaranteed sound power level LwA (cabin) | 106 dB(A) |
| Specified sound pressure level LpA (cabin) | 76 dB(A) |
| Operating voltage | 12 V |
| Battery | 185 Ah |
| Alternator | 150 A |
| Payload (max.) | 7.716 lb 3.500 kg |
| Operating weight | 15.984 lb 7.250 kg |
| Driver's cab | Kabine |
| Tank capacity for fuel | 37,51 US gal 142 l |
| Tank capacity for hydraulic oil | 23,78 US gal 90 l |
| Tank capacity for urea solution | 5,02 US gal 19 l |
| Type of drive | hydrostatisch (elektronisch geregelt) |
| Drive unit | Gelenkwelle |
| Speed levels | 3 |
| Axle | PAL 1930 |
| Travel speed Standard | 0-12,43 mph 0-20 km/h |
| Travel speed Option 1 | 0-18,64 mph 0-30 km/h |
| Travel speed Option 2 | 0-24,85 mph 0-40 km/h |
| Operating brake | Lamellenbremse in der Vorderachse über Gelenkwelle auf Hinterachse wirkend |
| Parking brake | Elektro-hydraulische Lamellenbremse mit Federspeicher in der Vorderachse, über Gelenkwelle auf Hinterachse wirkend |
| Differential lock | 100% Vorderachse (Option) |
| Drive hydraulics working pressure (max.) | 7252 psi 500 bar |
| Work hydraulics discharge volume (max.) | 36,61 (49,40) gpm 138,6 (187) l/min |
| Work hydraulics working pressure (max.) | 3785 psi 261 bar |
| Lifting cylinder | 1 |
| Tipping cylinder | 1 |
| Quick change system | mechanisch (hydraulisch) |
| Steering type | Hydrostatische Allradlenkung mit vollautomatischer Synchronisation |
| Steering cylinder | 2 |
| Steering angle max. | 2x45 Grad |
| Oscillating angle of the rear axle | ± 10 Grad |
| Free text |
DPF = Dieselpartikelfilter DOC = Dieseloxidationskatalysator SCR = Selektive katalytische Reduktion |
